Description
Samband for regi, produksjoner og konsertarrangementer
Retevis 5 er en digital modell med mange funksjoner og muligheter. Passer perfekt for deg som ønsker flere kanaler og bånd å jobbe på, utendørs eller på krevende lokasjoner.
Vi anbefaler tilbehør som klokker eller regi headsett.
Pakken leies ut som 1 kit som inneholder:
4 stk Radioer
4 stk Ørebøyler
1 stk Docking ladestasjon
Nødvendige kabler, belteclips o.l
TEKNISK
|
Color |
Black |
|
Dual band / dual display / dual standby |
A/B band independent operation( UV UU VU VV ) |
|
128 groups channels storage |
Shortcut menu operation mode |
|
VFO & Memory channels scan |
Emergency Alarm |
|
Time-out Timer (TOT) |
0~9 grades VOX selectable |
|
PTT & ANI ID |
FM radio and 25 stations storage |
|
Voice companding |
50 CTCSS/105 DCS |
|
High/Low TX power selectable |
DTMF function |
|
Wide/Narrow Band(25kHz/12.5kHz) |
Yes |
|
VOX function |
Yes |
|
Busy channel lock-out(BCLO) |
Yes |
|
Busy lockout function |
Yes |
|
Scanning function |
Yes |
|
Monitor function |
Yes |
|
Time-out Timer (TOT) function |
Yes |
|
LCD display |
Yes |
|
Dual display |
Yes |
|
Battery voltage display function |
Yes |
|
Channel name display and editing functions |
Yes |
|
Signal strength indicator |
Yes |
|
Keypad lock function |
Yes |
|
Built-in Led torch |
Yes |
|
FM radio |
Yes |
|
Wire clone function |
Yes |
|
Emergency alarm function |
Yes |
|
Low battery alarm |
Yes |
|
Power saving function |
Yes |
|
Tone end of transmission |
Yes |
|
Chinese and English voice prompt |
Yes |
|
PC software programmable |
Yes |
|
Basic Descriptions |
|
|
Rated Voltage |
7.4V DC±10% |
|
Output power |
5W |
|
Battery type |
Li-ion battery |
|
Channel |
128 |
|
Battery capacity |
1800mAh |
|
Working temperature |
-20~+50 ℃ |
|
Antenna Impedance |
50ohm |
|
Weight |
200g (Not Antenna) |
|
Dimension ( L x W x H ) |
110x58x32mm (Not Antenna ) |
|
Specification |
|
|
Frequency range |
UHF：400-520MHz + VHF：136-174MHz |
|
Frequency stability |
±2.5ppm |
|
High/Low TX power selectable |
VHF:5W/1W UHF:4W/1W |
|
Frequency step |
2.5/5/6.25/10/12.5/25kHz |
|
5ppm |
|
|
Modulation |
16kΦF3E / 11kΦF3E |
|
Max frequency deviation |
< 5kHz(Wide) < 2.5kHz(Narrow) |
|
Modulation character |
6 dB per fold frequency patch |
|
Emission current |
< 1.6A(5W) |
|
CTCSS / DCS |
0.5±0.1kHz(Wide) 0.3±0.1kHz(Narrow) |
|
Sensitivity |
< 0.16 µV(12dB SINAD) |
|
Silent sensitivity |
< 0.2 µV |
|
Intermediation Distortion |
<10% |
|
Inter modulation |
60dB |
|
Adjacent channel selectivity( wide/narrow) |
<-65dB(Wide) <-60dB(Narrow) |
