| ACOUSTIC DATA |
| Frequency Response (+- 2.5 dB) |
75 Hz to 21 kHz |
| Frequency Range (-10dB) |
60 Hz – 26 kHz |
| Sensitivity (1W/1m) |
94 dB SPL |
| Max Peak SPL(Band limited pink noise 6dB crest factor) |
122 dB SPL |
| Max SPL Long Term |
116 dB SPL AVG SPL @1M before protection band limited pink noise131 dB SPL Music Program Transient Peak |
| Coverage Horizontal |
100 degrees – 6 dB |
| Coverage Vertical |
40 degrees – 6dB |
| AMPLIFIER DATA |
| Amplifier Power (Long Term Sine Wave before protection) |
LF: 275 watts rmsHF: 40 watts rms |
| Amplifier Power ( AVG Burst@ 1% THD) |
LF: 600 watts rmsHF: 300 watts rms |
| Amplifier Protection |
Input limiter, short circuit protection, DC protection of output, under & over voltage protection, intelligent mains fuse protection, power stage overload protection, temperature protection of transformers and heat-sinks |
| Operational Voltage |
Universal Mains, 85-268V (dual voltage auto selection). UREC™ power supply integrated amplifier modules provides universal mains operation for 120 V and 230 V, eliminating the need for market specific self-powered loudspeakers and related reliability issues. |
| THD+N (typical) |
< 0.05 % (20 Hz – 20 kHz, 3 dB below rated power) |
| DSP |
96k Hz sample rate, mixed-mode 64-bit digital processing, 120 dB dynamic range, less than 600 microseconds latency |
